TÜRKAK Accredited Gas Calibration
Gas detector calibration under TS EN ISO/IEC 17025:2017, TURKAK code AB-0319-K.
Learn more
TÜRKAK AB-0319-K
TÜRKAK accredited gas calibration
ESA Calibration Laboratory calibrates fixed and portable gas detectors and leak detectors under TS EN ISO/IEC 17025:2017, code AB-0319-K.
TÜRKAK AB-0319-K
On-site field calibration
On-site calibration with reference gas and documented procedure to reduce process downtime. Field teams from Ankara and Izmir across Turkey.
TÜRKAK AB-0319-K
ATEX gas detectors, installation and service
Karf & Scoot, E2S and GDI Solution products; fixed-system installation, commissioning, spares and fault finding. 4-20 mA, relay and RS485 integration.
Our laboratory is accredited by TURKAK to TS EN ISO/IEC 17025:2017. The aim is traceable calibration results with international recognition.
CertificatesOur services
Calibration, service, installation
TÜRKAK accredited gas calibration, field calibration, detector technical service, commissioning and installation are planned under one roof.
Fixed Gas Detector Calibration
Verification of 4-20 mA, relays and LEL/ppm on explosion-proof fixed detectors.
Learn more
Portable Gas Detector Calibration
Traceable calibration of single- and multi-gas instruments after bump testing.
Learn more
Flue Gas Analyser Calibration
Accredited calibration of O2, CO, NO, SO2 and related flue-gas channels.
Learn more
Gas Detector Technical Service
Repair and spares for sensors, boards, displays and communications faults.
Learn moreProduct categories
Fixed, portable, ATEX, panels
Fixed and portable gas detectors, flame detectors, control panels and warning devices. ATEX / IECEx equipment is selected for the project.
Fixed gas detectors
Explosion-proof fixed detectors continuously monitor flammable, toxic gases and oxygen. GDSFX (display) and GD2G (no display) run on 24 VDC, IP65 aluminium, 4-20 mA, relays and RS485. ATEX II 2G Ex d IIC T6 Gb suits Zone 1/2. ESA supplies, installs and calibrates.
Portable gas detectors
Single-gas, multi-gas and portable leak detectors for personal and survey use. ATEX/IECEx models are used by field crews; ESA supplies cells, calibration and 17025 certificates after bump tests.
Flame detectors
IR/UV flame detectors see hydrocarbon and organic flames at tens of metres. IRT-110-K and IRT-021-A (explosion-proof) use 24 VDC, relays and optional 4-20 mA into fire-and-gas panels. Shipyards, military and process sites.
Gas detector control panels
GDMP series monitors gas and flame detectors with 2/4/8-channel 4-20 mA inputs, digital inputs, relays and Modbus. 220 VAC, IP65 aluminium. ESA installs, loop-tests and commissions panels.
Area warning equipment
Zone 1/2 xenon beacons (E2S BExBG05, 5 J, SIL 1/2) and break-glass manual call points (BExCP3-BG, SIL2). LM6 aluminium, dual M20 entries. They add visual and manual layers to gas-detection panels.
TÜRKAK accredited calibration services
ESA Calibration Laboratory (TURKAK AB-0319-K, TS EN ISO/IEC 17025:2017) calibrates fixed, portable and leak detectors and flue-gas analysers. Laboratory at Ivedik OSB; field work nationwide.
Featured products
Karf & Scoot, E2S, GDI
GDSFX and GD2G fixed detectors, E2S explosion-proof beacons and break-glass call points, GDI BELLMINI portable detectors. Send the model and target gas for a quote.
Karf & Scoot
Karf & Scoot GDSFX Catalytic (Pellistor) Display Ex-proof Fixed Gas Detector
Catalytic pellistor for flammables, LCD, 24 VDC, IP65, 4-20 mA, 3 relays, RS485, ATEX II 2G Ex d IIC T6 Gb.
Request a quote
Karf & Scoot
Karf & Scoot GDSFX Infrared (IR) Display Ex-proof Fixed Gas Detector
IR sensor for hydrocarbons, refrigerants and CO2; LCD, 24 VDC, IP65, 4-20 mA / relays / RS485, ATEX II 2G Ex d IIC T6 Gb.
Request a quote
Karf & Scoot
Karf & Scoot GDSFX Electrochemical Display Ex-proof Fixed Gas Detector
ppm monitoring of CO, H2S, NH3, SO2 and O2; LCD, 24 VDC, IP65, 4-20 mA / relays / RS485, ATEX II 2G Ex d IIC T6 Gb.
Request a quote
Karf & Scoot
Karf & Scoot GD2G Catalytic (Pellistor) No-Display Ex-proof Fixed Gas Detector
No-display catalytic fixed head; 16–32 VDC, 3 relays, 4-20 mA, IP65 aluminium, ATEX/IECEx Zone 1/2.
Request a quote
Karf & Scoot
Karf & Scoot GD2G Infrared (IR) No-Display Ex-proof Fixed Gas Detector
IR head without display; hydrocarbons and CO2, 24 VDC nominal, 4-20 mA and 3 relays, IP65, ATEX/IECEx Zone 1/2.
Request a quote
Karf & Scoot
Karf & Scoot GDMP Series Gas and Flame Detector Monitoring Control Panel
2/4/8-channel 4-20 mA, 2 digital inputs, 2 relays, Modbus, 220 VAC, IP65 aluminium body.
Request a quote
Karf & Scoot
Karf & Scoot IRT Series IRT-021-A Ex-proof Flame Detector
3 IR, Zone 1/2 ATEX, stainless steel, 24 VDC, relays / optional 4-20 mA, range up to 50 m.
Request a quote
E2S
E2S Warning Signals BExBG05 Ex-proof Beacon
5 J xenon, 120 candela, Zone 1/2/21/22, SIL 1/2, LM6 aluminium, dual M20, auto-sync.
Request a quoteBrands
Supply and service network
We supply, spare and service Karf & Scoot, E2S, GDI Solution, Draeger, Honeywell, MSA, Oldham, Woelke and Industrial Scientific equipment.
Reference applications
Laboratory, field, installation, service
TURKAK calibration, OSB field work, portable fleets and ATEX installation examples.
Organised industrial zones
OSB fixed detector field calibration
On-site field calibration
View application
Sites across Turkey
ATEX fixed-system installation and commissioning
Installation / commissioning
View application
ESA technical service, Ankara
Technical service, cell and board repair
Technical service
View applicationField and laboratory
On-site calibration
When instruments cannot be removed or downtime is limited, we plan on-site calibration. Reference gas and procedure follow the accredited scope.
Laboratory
Ivedik OSB, Ankara
Fixed and portable detectors are calibrated in the laboratory with traceable gases.
Laboratory serviceField
Calibration at your site
On-site work with reference gas and documented procedure to reduce downtime.
Field serviceWhy ESA Gaz Kalibrasyon?
Accreditation, field, ATEX, service
TURKAK accreditation, lab plus field capacity, an ATEX product range, technical service and fast quoting from Ankara sit in one team.
TURKAK accreditation
Traceable calibration certificates under TS EN ISO/IEC 17025:2017, code AB-0319-K.
Field and laboratory
Ivedik OSB laboratory or on-site calibration planned around your downtime.
ATEX products
Ex d gas detectors, beacons and break-glass call points for Zone 1/2.
Technical service
Sensor replacement, board repair, firmware and 4-20 mA / RS485 signal checks.
Fast quotation
Same-day guidance from model, gas and quantity; WhatsApp or the form.
Ankara hub
Yenimahalle HQ, Ivedik laboratory and Izmir office covering sites nationwide.
Certificates
Accreditation and quality
The TURKAK accreditation certificate, calibration scope and decision-rule / statement of conformity are available on the documents page.
TURKAK accreditation certificate (AB-0319-K)
TURKAK accreditation certificate AB-0319-K issued to ESA Calibration Laboratory under TS EN ISO/IEC 17025:2017. Valid 6 Aug 2024 – 6 Aug 2028.
Decision rule / statement of conformity
T-17/02 decision-rule and statement-of-conformity instruction used when calibration results are tied to a declaration of conformity.
Calibration scope
Quantities, instrument types and ranges calibrated under TURKAK AB-0319-K (annex to the accreditation certificate).
ESA in figures
Accreditation and capacity
Technical notes
Calibration and accreditation
What gas calibration is, when to calibrate and what accreditation means — short guides for plant teams.
Gas Leak Detector Guide: Choosing the Right Device and Understanding Calibration
Learn how to choose a gas leak detector for your application and understand the importance of gas compatibility, functional testing and calibration.
Gas testing before confined-space entry
Before entry, test oxygen, LEL then toxics. A calibrated gas detector is part of confined-space safety.
Why measure phosphine (PH₃) during fumigation?
Phosphine is effective in grain fumigation but highly toxic. Pump PH₃ detectors and calibration.
Frequently asked questions
TURKAK, interval, ATEX, quotes
What is your TURKAK accreditation code?
ESA Calibration Laboratory is accredited by TURKAK to TS EN ISO/IEC 17025:2017 under code AB-0319-K. The current scope PDF is on the documents page.
Do you perform field calibration?
Yes. If removal is impractical or downtime is limited, we plan on-site calibration. Reference gas and records follow the 17025 procedure.
What calibration interval should we use?
Follow the manufacturer, process risk and previous deviations. Six or twelve months is common for many gas detectors; do not wait after doubtful readings, shock or cell replacement.
Do you sell and install ATEX products?
Yes. We supply and commission Ex d / Zone 1-2 gas detectors, beacons and break-glass call points, including Karf & Scoot, E2S and GDI Solution.
What do you need for a quotation?
Brand and model, target gas, quantity, laboratory or field, due date and any fault code. WhatsApp (0533 659 91 60) or the quote form is enough.
Sectors
Oil, chemicals, energy, industrial parks
Oil and gas, chemicals, energy, mining, food, pharma, shipyards and organised industrial zones.
Petrol & gaz
Field calibration and ATEX spares for LEL and H2S fixed lines on refinery and storage sites.
Kimya
17025-certified verification of electrochemical and PID heads on reactor and filling lines.
Enerji
Calibration of flue-gas analysers and fixed CO/O2 monitoring in plants and boiler houses.
Madencilik
Portable multi-gas and fixed methane monitoring on underground and conveyor routes.
Gıda
Refrigerant / CO2 leak and ambient monitoring calibration in cold rooms and filling.
İlaç
Low-ppm VOC and oxygen monitoring in cleanrooms and solvent areas.
Tersane
Portable fleets for confined-space entry and service of fixed heads on staging.
OSB
Panel, beacon and annual calibration contracts in organised industrial zones.
Request a quote
Model, gas, quantity, field/lab
Send brand-model, target gas, quantity and whether calibration is in the laboratory or on site. WhatsApp or the quote form is enough.
